The Sveaverken ND67 Outdoor LoRaWAN® Gateway is the essential communication hub for the MooCollar Bree Smart Cow Monitoring System. It wirelessly receives cow activity, rumination, and feeding data collected by MooCollar Bree collars and transmits it to the cloud via Ethernet, 4G LTE, or Wi-Fi, enabling farmers to monitor herd health and detect estrus through intelligent data analysis.
| Specification | Details |
|---|---|
| Model | ND67 |
| Product Type | Outdoor LoRaWAN® Gateway |
| Wireless Technology | LoRaWAN® |
| Network Connectivity | Ethernet, 4G LTE Cellular, Wi-Fi |
| Recommended Network Connection | Ethernet + 4G Cellular |
| Ethernet Interface | RJ45 Ethernet Port with PoE Support |
| Cellular Connectivity | 4G LTE with SIM Card Slot |
| Wi-Fi Connectivity | Supports Wi-Fi network connection and wireless configuration |
| LoRa Antennas | 2 External LoRa Antennas (60 cm each) |
| Antenna Configuration | Direct Antenna Installation or Coaxial Cable Installation |
| Power Supply | IEEE 802.3af PoE / 12V DC / Solar Power Supply via DC Connector |
| DC Power Connector | M12 Connector, 12V DC Input |
| Dimensions | 164 × 255.2 × 104.5 mm (W × H × D, overall dimensions shown in the guide, excluding antennas) |
| Status Indicators | SYS (System), LoRa (LoRaWAN Status), LTE (Cellular Status) |
| Additional Interfaces | USB Type-C Port, Reset Button |
| Device Management | Web-Based Management Interface (Web GUI) |
| Network Configuration | Ethernet, Cellular APN, Wi-Fi Client Mode, WAN Failover Configuration |
| Installation Options | Wall Mounting / Pole Mounting |
| Recommended Installation Height | Above 2.5 m; 3 m Recommended |
| Regulatory Compliance | CE, FCC, TELEC, RCM, ANATEL, RoHS (as declared in the guide) |
| Item | Quantity |
|---|---|
| ND67 Outdoor LoRaWAN® Gateway | 1 |
| LoRa Antennas (60 cm) | 2 |
| Mounting Bracket | 1 |
| RJ45 Cable Gland | 1 |
| SIM Dust Cover | 1 |
| Wall Mounting Kits | 4 |
| PoE Injector | 1 |
| DC Power Cable | 1 |
| Hose Clamps | 2 |
